Item
No
Part Number Qty Description Remarks
1 1002917-29 1 Air Inlet Hood
2 1016249-30 2 Hose Clamp
3 1010255 1 Air Breather Assembly
REF 1009253-17 1 Primary Air Filter
REF 1009253-16 1 Secondary Air Filter
4 1019244-02 1 Intake Reducer Elbow, 22°, 3.50” to 3.00”
5 1016249-29 2 Hose Clamp
6 1013710-02 1 Lower Intake Pipe
7 1009384-02 1 Reducing Elbow, 90°
8 1016249-28 1 Hose Clamp
9 1009253-31 1 Alternator Bracket
10 1009253-21 1 Alternator
11 1009253-20 1 Fan Belt
12 1016478-01 1 Radiator Fan
13 986537-17 1 Front Engine Mount - Left
14 986537-16 1 Front Engine Mount - Right
15 988673-14 2 Rear Engine Mount
16 986537-14 4 Engine Isolator
17 1017061 8 Engine Mount Washer
18 986810 8 Washer, Lock, 1/2, Nord Wedge
19 986537-03 1 Oil Filter
20 1011364 1 Tail Pipe
21 986537-66 1 Mass Air Flow Sensor
Engine Assembly - Intake/Exhaust
7
Illustrated Parts List
LeeBoy 8510E Conveyor Paver 7-43
