LeeBoy 8510E - Page 261

Item
No
Part Number Qty Description Remarks
REF 1018911 1 Lower Manifold Assembly w/ORFS Adapters
1 FS6400-04-04-O 2 Straight Adapter, -4 ORFS/-4 O-Ring
2
FS6802-12-12-NWO-FG
1 Elbow Adapter, 45°, -12 ORFS/-12 O-Ring
3
FS6801-04-08-NWO-FG
1 Elbow Adapter, 90°, -4 ORFS/-8 O-Ring
4
FS6801-04-04-NWO-FG
1 Elbow Adapter, 90°, -4 ORFS/-4 O-Ring
5 FS6400-08-06-O 1 Straight Adapter, -8 ORFS/-6 O-Ring
6 FS6400-06-08-O 1 Straight Adapter, -6 ORFS/-8 O-Ring
7
FS6802-06-08-NWO-FG
1 Elbow Adapter, 45°, -6 ORFS/-8 O-Ring
8
FS6802-06-06-NWO-FG
1 Elbow Adapter, 45°, -6 ORFS/-6 O-Ring
9 FS6400-10-08-O 2 Straight Adapter, -10 ORFS/-8 O-Ring
10 FS6500-10-10-FG 3 Swivel Elbow Adapter, 90°, -10 ORFS/-10 ORFS
11 FS6400-06-06-O 4 Straight Adapter, -6 ORFS/-6 O-Ring
12 FS6400-08-08-O 4 Straight Adapter, -8 ORFS/-8 O-Ring
13 FS6400-10-10-O 1 Straight Adapter, -10 ORFS/-10 O-Ring
14 FS6400-08-10-O 4 Straight Adapter, -08 ORFS/-10 O-Ring
15 1018059 1 Lower Manifold Includes Items 16-25
16 1018059-04 2 Cartridge
17 986972-02 3 12VDC Coil
18 1018059-06 2 Solenoid Cartridge
19 1001686-03 2 Valve Coil
20 984579-10 1 Flow Divider
21 1018059-06 1 Solenoid Cartridge
22 1018059-03 1 Solenoid Cartridge
23 984657-06 1 12VDC Coil
24 1018059-02 2 Relief Valve Cartridge
Hydraulic Manifold - Lower
7
Illustrated Parts List
LeeBoy 8510E Conveyor Paver 7-55
