Hydraulic Cylinders
Item
No
Part Number Qty Description Remarks
1 1014284SRV 2 Screed Lift Cylinder, 2.50 x 12.00 x 1.00
2 6801-6-6 NWO 4 Elbow Adapter, 90°, -6 JIC/-6 O-Ring
REF 1019174 2 Hydraulic Cylinder, Cut Off w/Adapters
Includes Items 3-7
3 910170 2 Hydraulic Cylinder, 2.50 x 4.00 x 1.25
- 910170-01 A/R Seal Kit for Item# 3
Not Shown
4 1011476 10 Clevis Pin, 1.00 x 2.50
5 80336 10 Cotter Pin, 3/16" x 1.50"
6 FS2503-06-06-FG 2 Elbow Adapter, 45°, -6 ORFS/-6 NPTF
7 FS2501-06-06-FG 2 Elbow Adapter, 90°, -6 ORFS/-6 NPTF
REF 1019171 1 Conveyor Lift Cylinder w/Adapters
Includes Items 8-10
8 1016711 1 Conveyor Lift Cylinder, 3.00 x 9.00
9
FS6802-06-06-NWO-FG
1 Elbow Adapter, 45°, -6 ORFS/-6 O-Ring
10
FS6801-06-06-NWO-FG
3 Elbow Adapter, 90°, -6 ORFS/-6 O-Ring
REF 1019176 1 Hopper Wing Sequence Manifold Assembly
Includes Items 10-12
11 910122 1 Hopper Wing Sequence Manifold
12 FS6400-06-06-O 4 Straight Adapter, -6 ORFS/-6 O-Ring
REF 1018912 1 Charge Filter Assembly
Includes Items 13-17
13 290030 1 Hydraulic Filter Element, 9 Micron
14 1017402 1 Hydraulic Filter Head, HMK04
15 FS6801-10-12-NWO-FG 1 Elbow Adapter, 90°, -10 ORFS/-12 O-Ring
16
FS6804-10-12-10-NWO-FG
1 Run Tee Adapter, -10 ORFS/-12 O-Ring/-10 ORFS
17 FS2406-10-04 1 Straight Reducer Adapter, -10 FFORX/-4 ORFS
7
Illustrated Parts List
LeeBoy 8510E Conveyor Paver 7-57
