Item
No
Part Number Qty Description Remarks
1 851206 2 Screed Front Pull Arm (1) Left, (1) Right
2 100-10-11-40-5 2 CSHH, 5/8-11 x 2.50, GR5 (1) Left, (1) Right
3 204-10-11-5 6 Nut, Lock, Stover, 5/8-11, GR5 (3) Left, (3) Right
4 100-16-8-40-5 2 CSHH, 1-8 x 2.50, GR5 (1) Left, (1) Right
5 204-16-8-5 2 Nut, Lock, Stover, 1-8, GR5 (1) Left, (1) Right
6 851210 4 Screed Pull Arm Pivot Ears (2) Left, (2) Right
7 100-10-11-36-5 4 CSHH, 5/8-11 x 2.25, GR5 (2) Left, (2) Right
8 300-10 4 Washer, Flat, SAE, 5/8 (2) Left, (2) Right
9 851520 2 Push/Pull Cable, 90" x 5" Stroke (1) Left, (1) Right
10 350050 2 Clevis, 1/4-28 (1) Left, (1) Right
11 100-4-20-20-5 2 CSHH, 1/4-20 x 1.25, GR5 (1) Left, (1) Right
12 204-4-20-5 2 Nut, Lock, Stover, 1/4-20, GR5 (1) Left, (1) Right
13 851209 2 Screed Pull Arm Pivot Mount (1) Left, (1) Right
14 100-6-16-16-5F 4 CSHH, 3/8-16 x 1.00, GR5, FT (2) Left, (2) Right
15 302-6 4 Washer, Lock, 3/8 (2) Left, (2) Right
16 308-6-24 4 Washer, Flat, Fender, 3/8 x 1.50 (2) Left, (2) Right
17 100-7-20-28-5 2 CSHH, 7/16-20 x 1.75, GR5 (1) Left, (1) Right
18 204-7-20-5 2 Nut, Lock, Stover, 7/16-20, GR5 (1) Left, (1) Right
19 853853L 1 Electric Screw Assembly - Left Includes Items 20 - 24
REF 853853R 1 Electric Screw Assembly - Right Not Shown, Includes Items 20 - 24
20 851518 2 Linear Actuator, 6.00, 12V (1) Per Assembly
21 851211 2 Electric Screw Rod End Clevis (1) Per Assembly
22 851212 2 Linear Actuator Rod Weldment (1) Per Assembly
23 100-8-13-40-5 4 CSHH, 1/2-13 x 2.50, GR5 (2) Left, (2) Right
24 204-8-13-5 4 Nut, Lock, Stover, 1/2-13, GR5 (2) Left, (2) Right
25 856472 2
Decal - Thicker/Thinner (1) Left, (1) Right
Tow Point Assembly
7
Illustrated Parts List
LeeBoy 8510E Conveyor Paver 7-65
