LeeBoy 8510E - Page 281

High Deck Controls - Left (2 of 2)
Item
No
Part Number Qty Description Remarks
38 1017901FLS 1 Electronic Valve Float Section
39 910056 1 Outlet Cover, V-20
40 1019223 1 Decal - Manual Controls, Left
41 350050 7 Clevis, 1/4-28
42 920136 5 Push/Pull Cable, 136” x 3” Sroke Not All Shown
43 1018562 1 Lower Control Assembly Includes Items 5,6,45-48
44 1018563 1 Lower Control Weldment
45 1018568 1 Lower Control Handle Pivot Bar
46 920210A 1 Control Handle
47 100-6-24-16-5F 2 CSHH, 3/8-24 x 1.00, GR5, FT
48 920120 1 Push/Pull Cable, 104” x 3” Stroke
7
Illustrated Parts List
LeeBoy 8510E Conveyor Paver 7-75
