LeeBoy 8510E - Page 283

High Deck Controls - Right
Item
No
Part Number Qty Description Remarks
REF 1018555 1 High Deck Controls Assembly - Right Includes Items 1-9
1 1018556 1 High Deck Controls Weldment - Right
2 1019386 1 Electronic Steer Tee
3 920070 3 Thumb Screw, 3/8-16 x 1.00
4 920210 4 Control Handle - Right
5 1012776 1 Control Handle Pivot Rod - Right
6 350050 7 Clevis, 1/4-28
7 100-6-24-16-5F 4 CSHH, 3/8-24 x 1.00, GR5, FT
8 302-6 9 Washer, Lock, 3/8
9 300-6 9 Washer, Flat, SAE, 3/8
10 100-5-18-16-5 4 CSHH, 5/16-18 x 1.00, GR5, FT
11 302-5 4 Washer, Lock, 5/16
12 300-5 4 Washer, Flat, SAE, 5/16
13 126-5-16-12 7 Set Screw, Hex Socket, Oval, 5/16-18 x .75
14 200-5-18-5 7 Nut, Hex, 5/16-18, GR5
15 1019939 1 High Deck Controls Brace - Right
16 100-6-24-12-5F 1 CSHH, 3/8-24 x .75, GR5, FT
17 1019224 1 Decal - Manual Controls, Right
18 1018562 1 Lower Control Assembly Includes Items 7-9,19-21
19 1018563 1 Lower Control Weldment
20 1018568 1 Lower Control Handle Pivot Bar
21 920210A 1 Control Handle
22 100-6-16-16-5F 4 CSHH, 3/8-16 x 1.00, GR5, FT
7
Illustrated Parts List
LeeBoy 8510E Conveyor Paver 7-77
