LeeBoy 8510E - Page 287

Joystick Controls
Item
No
Part Number Qty Description Remarks
GRP 1019211 Group - Dual Joystick
1 853836 1 Steer Box Mount - Left
2 853836L 1 Steer Box Mount - Right
3 1002546SRV 1 Cup Holder - Left
4 1002547SRV 1 Cup Holder - Right
5 490010 2 Hand Grip
6 1016272SRV 2 Dual Joystick Control Box
7 100-4-20-16-5F 8 CSHH, 1/4-20 x 1.00, GR5, FT
8 300-4 16 Washer, Flat, SAE, 1/4
9 204-4-20-5 8 Nut, Lock, Stover, 1/4-20, GR5
10 986539 2 Decal - Operation, Dual Joystick
7
Illustrated Parts List
LeeBoy 8510E Conveyor Paver 7-81
