LeeBoy 8510E - Page 289

Control Box Slide Assembly
Item
No
Part Number Qty Description Remarks
REF 1018547 1 Control Box Slide Assembly Includes Items 1-13
1 1010133 1 Vandalism Cover Assembly
2 853922 1 Vandalism Lock Tee Handle - 7” Included With Item 1
3 1014776 1 Control Box Slide Tube Assembly
4 1014814 1 Support Arm Plate - Left
5 1014815 1 Support Arm Plate - Right
6 1014810 2 Slide Tube Angle Adjuster
7 1014898 2 Grab Handle
8 490010 2 Hand Grip
9 100-6-24-32-5 2 CSHH, 3/8-24 x 2.00, GR5
10 302-6 6 Washer, Lock, 3/8
11 300-6 16 Washer, Flat, SAE, 3/8
12 100-6-16-16-5F 10 CSHH, 3/8-16 x 1.00, GR5, FT
13 200-6-16-5 10 Nut, Hex, 3/8-16, GR5
14 100-5-18-16-5 4 CSHH, 5/16-18 x 1.00, GR5
15 302-5 4 Washer, Lock, 5/16
16 300-5 4 Washer, Flat, SAE, 5/16
17 871111609 2 Insulated Clamp
18 100-4-20-12-5F 4 CSHH, 1/4-20 x .75, GR5, FT
19 300-4 8 Washer, Flat, SAE, 1/4
20 204-4-20-5 4 Nut, Lock, Stover, 1/4-20, GR5
21 1018792 1 Control Box Assembly
7
Illustrated Parts List
LeeBoy 8510E Conveyor Paver 7-83
