Item
No
Part Number Qty Description Remarks
REF 1016967 1 Seat Assembly, Short Post Includes Items 1-6
1 360010 2 White Seat Assembly w/Armrest
2 988640SRV 2 Seat Post Assembly - Short
3 200-5-18-5 12 Nut, Hex, 5/16-18, GR5
4 302-5 16 Washer, Lock, 5/16
5 300-5 16 Washer, Flat, SAE, 5/16
6 984862 8 Vinyl Cap - Black
7 72836 2 Pin, 1/2 x 3.00 w/Cotter Pin
8 160320 1 Back Up Alarm, 107 dB
9 853963 1 Tool Box
10 20190773 1 Horn, Low Pitch
11 1013307 4 Circular LED Light w/Deutsch
12 100-5-18-16-5 4 CSHH, 5/16-18 x 1.00, GR5
13 1018435 1 Beacon Light Assembly Includes Items 14-18
REF 1013231 1 Beacon Light, LED Amber Strobe
14 1018434 4 Beacon Light Mount
15 122-#10-24-12F 3 PHMS, Cross, #10-24 x .75, FT
16 300-#10 3 Washer, Flat, SAE, #10
17 205-#10-24-5 3 Nut, Lock, Nylon, #10-24, GR5
18 985234-01 1 Manual Case Mounted on Screed
19 1016514 1 Tool Tray Assembly Mounted on Screed
20 100-6-16-28-5 2 CSHH, 3/8-16 x 1.75, GR5 Mounted on Screed
21 300-6 4 Washer, Flat, SAE, 3/8 Mounted on Screed
22 204-6-16-5 2 Nut, Lock, Stover, 3/8-16, GR5 Mounted on Screed
23 100-4-20-16-5 4 CSHH, 1/4-20 x 1.00, GR5 Mounted on Screed
24 300-4 8 Washer, Flat, SAE, 1/4 Mounted on Screed
25 204-4-20-5 4 Nut, Lock, Stover, 1/4-20, GR5 Mounted on Screed
Seat Assembly & Details
7
Illustrated Parts List
LeeBoy 8510E Conveyor Paver 7-89
