Option - Legend Screed Slide Plates
Item
No
Part Number Qty Description Remarks
1 1002186 2 Screed Fiber Bushing Slide Assembly Includes Items 1-5
2 1002181 2 Slide Assembly with Fiber Bushings Includes Items 3-4
3 988588 8 Fiber Bushing (4) Per Assembly
4 851256 8 Snap Ring (4) Per Assembly
5 988601 4 Screed Extension Shaft - Chrome (2) Per Assembly
6 100-8-20-24-5 8 CSHH, 1/2-20 x 1.50, GR5 (4) Per Assembly
7 986810 8 Washer, Lock, 1/2, Nord Wedge (4) Per Assembly
7
Illustrated Parts List
LeeBoy 8510E Conveyor Paver 7-99
