LeeBoy 8510E - Page 339

Item
No
Part Number Qty Description Remarks
GRP 1007206 1 Group - Standard Depth Screws
REF 1011374SRV 2 Screed Thickness Adjuster Assembly
1 1011375SRV 2 Thickness Adjuster Handle Weldment (1) Per Assembly
2 1006434 2 Adjuster Screw Cap (1) Per Assembly
3 100-4-20-12-5F 4 CSHH, 1/4-20 x .75, GR5, FT (2) Per Assembly
4 300-4 4 Washer, Flat, SAE, 1/4 (2) Per Assembly
5 204-4-20-5 4 Nut, Lock, Stover, 1/4-20, GR5 (2) Per Assembly
6 95998936 2 Lock Nut, PTORQ, 3/4-16 (1) Per Assembly
7 301-12 2 Washer, Flat, USS, 3/4 (1) Per Assembly
8 981574 4 Revolving Ball Knob, M12x1.75 (2) Per Assembly
9 200-M12-1.75-8.8 4 Nut, Hex, M12x1.75, C8.8 (2) Per Assembly
10 302-8 4 Washer, Lock, 1/2 (2) Per Assembly
11 810110 4 Push Roller Bearing, ø1.250 (2) Per Assembly
12 20931333 2 Tongued Washer, 1.21 ID x 1.86 OD (1) Per Assembly
13 95200978 2 Lockwasher (1) Per Assembly
14 95200879 2 Locknut (1) Per Assembly
15 1011307 2 Thickness Adjuster Shaft (1) Per Assembly
16 1011309 2 Key, .25 x .25 x 1.25 (1) Per Assembly
17 21426507 2 Universal Joint (1) Per Assembly
18 20160644 4 Spirol Pin, ø3/8 x 1.75 (2) Per Assembly
REF 20960332 A/R Universal Joint Bearing
19 1006431 2 Adjuster Screw (1) Per Assembly
20 1006429 2 Adjuster Sleeve w/Ball Joint (1) Per Assembly
HD Screed Thickness Adjuster - Standard
7
Illustrated Parts List
LeeBoy 8510E Conveyor Paver 7-133
