Description Part No.
Item
No.
FIgure
No.
Conveyor Cutoff Hinge Weldment - Left 1016522 29 7-6
Conveyor Cutoff Hinge Weldment - Right 1016525 39 7-6
Conveyor Drive Motor Sprocket 851120 18 7-6
Conveyor Drive Shaft 851116 4 7-6
Conveyor Drive Shaft Snap Ring 850040 5 7-5
Conveyor Drive Shaft Snap Ring 850040 7 7-6
Conveyor Drive Sprocket 1019092 11 7-6
Conveyor Drive Sprocket Washer 851112 10 7-6
Conveyor Drive Tension Adjuster Weldment 1014196 22 7-6
Conveyor Flap Hinge Pin - Left 1015297 31 7-6
Conveyor Flap Hinge Pin - Right 1015298 41 7-6
Conveyor Flight Chain Bar 851118A 11a 7-5
Conveyor Flight Clean Out Bar 1014959 11b 7-5
Conveyor Floor Plate 851627SRV REF 7-5
Conveyor Front Guide Tube Assembly 851123 1 7-5
Conveyor Front Guide Wheel 850120 4 7-5
Conveyor Idler Shaft 851124 2 7-5
Conveyor Lift Cylinder w/Adapters 1019171 REF 7-22
Conveyor Lift Cylinder w/Adapters 1019171 REF 7-23
Conveyor Lift Cylinder, 3.00 x 9.00 1016711 8 7-22
Conveyor Lift Cylinder, 3.00 x 9.00 1016711 8 7-23
Conveyor Pan, Front - Left 855882 30 7-4
Conveyor Pan, Front - Right 855879 26 7-4
Conveyor Pan, Rear - Left 855881 29 7-4
Conveyor Pan, Rear - Right 855878 25 7-4
Conveyor Plate Washer 855346 10 7-4
Conveyor Switch Arm 900060-1SRV 35 7-6
Conveyor Switch Linkage, Rod 900075 36 7-6
Conveyor Tube Assembly 851651 3 7-6
Coolant Recovery Tank 986537-46 14 7-14
Cooler Mount Weldment - Top 1016567 2 7-20
Cooler Mounting Brace 1016708 4 7-20
Cotter Pin, .148, #9 5928 24 7-62
Cotter Pin, .148, #9 5928 24 7-63
Cotter Pin, .177, 7 GA 870307 10 7-1
Cotter Pin, .177, 7 GA 870307 7 7-2
Cotter Pin, .188 x 1.50 80336 14 7-7
Cotter Pin, .188 x 2.00 80338 12 7-8
Cotter Pin, .188 x 2.00 80338 9 7-74
7
Alphabetical Parts Index
LeeBoy 8510E Conveyor Paver 7-193
