Description Part No.
Item
No.
FIgure
No.
Side Access Door Assembly - Right 1016416 REF 7-24
Side Planetary Mount Plate 1014923 28 7-65
Side Strip Flashing 985062 19 7-7
Sidewing Rubber 980728 3 7-7
Ski, 20’, Front 985190 10 7-71
Ski, 20’, Rear 985191 17 7-71
Skid 851249 1 7-71
Slide Assembly with Fiber Bushings 1002181 2 7-40
Slide Locking Bar 1006424 9a 7-51
Slide Tube Angle Adjuster 1014810 6 7-33
Slope Module Cable (8 ft.) 1010499-10 22 7-73
Slope Pin 981659 6 7-51
Slope Pivot Poly Bushing 981838 5 7-51
SMS Test Hose Assembly w/#4 Female JIC-48" 1013588-48 REF 7-13
SMS Test Hose Assembly w/#4 Female JIC-96" 1013588-96 REF 7-13
Snap Ring 851256 4 7-40
Solenoid Cartridge 1018059-06 18 7-21
Solenoid Cartridge 1018059-06 21 7-21
Solenoid Cartridge 1018059-03 22 7-21
Sonic Sensor Bracket Weldment 1015380 14 7-58
Sonic Sensor Bracket Weldment 1015380 19 7-66
Sonic Sensor Bracket Weldment 1015380 24 7-67
Sonic Sensor Mount 1008905 16 7-58
Sonic Sensor Mount 1008905 21 7-66
Sonic Sensor Mount 1008905 26 7-67
Sonic Tracker Bracket Assembly w/L-Bolt 1010499-02 7 7-73
Sonic Tracker Bracket Assembly w/L-Bolt 1010499-02 7 7-73
Sonic Tracker Bracket Assembly w/L-Bolt 1010499-02 REF 7-73
Sonic Tracker II Assembly 1010499-06 15 7-73
Sonic Tracker II Assembly 1010499-06 15 7-73
Spiral Internal Spring, 2.00 ID Shaft 980380 4 7-55
Spirol Pin, ø3/8 x 1.75 20160644 18 7-57
Spirol Pin, ø3/8 x 1.750 20160644 36 7-65
Spray Down Handle & Nozzle 920220 26 7-25
Spray Down Holder - Left 1016836 27 7-25
Spray Down Holder - Right 1019122 28 7-25
Spray Down Nozzle 901210A REF 7-25
Spray Down Pump Body 1015438-01 2 7-25
Spray Down Pump w/Pressure Switch 1015438 REF 7-25
7
Alphabetical Parts Index
LeeBoy 8510E Conveyor Paver 7-223
