4
LeeBoy 8510E Conveyor Paver 4-11
Operation
Figure 4-14. Machine Inhibiting DPF Regeneration
Screen
Figure 4-15. Parked Regeneration Overview Screen
Lamp Info
Scroll through the Menu list using the UP/DOWN soft
keys and stop the cursor (>) next to the action item
Lamp Info. Press the select ( ) soft key.
This screen shows the Diesel Particulate Filter
(DPF) Lamp symbols and provides a description and
cautionary information for each symbol. Use the UP/
DOWN soft keys to scroll to each symbol. (Figures 4-12
to 4-15)
Figure 4-12. High Exhaust Temperature Due to DPF
Regeneration Symbol Screen
Figure 4-13. Needs Regenerating Screen
