Table 2-8. 815HD (Heavy Duty) and HD PRO (Option) Screed Specications
ITEM 815HD SCREED HD PRO SCREED (Option)
Screed Weight 3450 lbs 4150 lbs
Electric Heat Elements
Two (2) 3000-watt S-Curve elements on main
screed.
One (1) 1500-watt sealed blade element in each
screed extension.
Two (2) 3500-watt S-Curve elements on main
screed.
One (1) 2000-watt sealed blade element in
each screed extension.
Main Screed Width 8 ft 8 ft
Screed Extension Width (2,
Hydraulically-Operated)
3 ft 8 in 3 ft 10 in
Wear Plates
Main Screed Depth: 18 in [.375 in Thick]
Extension Depth: 7.38 in [.375 in Thick]
Main Screed Depth: 18 in [3/8 in Thick]
Extension Depth: 9 in [3/8 in Thick]
Bullnose Radius
Main Screed: 2 in
Screed Extension: 1.5 in
Main Screed: 1.688 in
Screed Extension: 1.688 in
Vibration Two (2) vibration motors producing 4100 vpm Two (2) vibration motors producing 4100 vpm
Slope @ Maximum Width 3.5 in 4 in
Crown/Valley @ 10 ft (3 m)
Positive Crown: 2.5 in
Negative Crown: 1.5 in
Positive Crown: 2.5 in
Negative Crown: 1.5 in
End Gate
Spring loaded with vertical height adjustments
and tilt.
Spring loaded with vertical height adjustments
and tilt.
Table 2-9. Electrical Specications
ITEM SPECIFICATION
Battery (1) 12 Vdc Maintenance Free, 12 Volts, Negative Ground
Cold Cranking Amps (CCA) 1150 CCA
Alternator 100 Amp
Starter Voltage and Type 12-Volt, Negative-Ground
Circuit Protection Fuses, Breakers and Disconnect
Table 2-10. Generator Specications
ITEM SPECIFICATION
Power 14,400 watt
Voltage 120/240 Volts
Frequency 57 - 63 Hz
Table 2-11. Track Specications
ITEM SPECIFICATION
Poly/Steel (2-Speed, 35 Pads)
Length: 94 in
Width: 14 in
Smooth Poly/Steel (2-Speed, 35 Pads)
Length: 94 in
Width: 14 in
