Description Part Number Figure Number Item Number
Assembly, Engine Cover, Tier 4 1010587 7-13 1
Assembly, Extension Heatbox 1006380SRV 7-23 1
Assembly, Extension Heatbox 1006380SRV 7-24 1
Assembly, Fuel Tank 1007084SRV 7-8 5
Assembly, Guide Bar, Left 1008730SRV 7-1 21
Assembly, Heated Edge Endgate (Left) 1011187SRV 7-30 -
Assembly, Heated Edge Endgate (Right) 1011156SRV 7-29 -
Assembly, Heated Endgate (Left) 1011148 7-28 1
Assembly, Heated Endgate (Right) 1011149 7-27 1
Assembly, Hydraulic Tank 1007083SRV 7-8 1
Assembly, Inner Sprocket 1007062SRV 7-3 23
Assembly, Inner, Extension Mount, Left 1007097SRV 7-23 14
Assembly, Lower Thickness Adjuster 1011373 7-33 4
Assembly, New Style Seat Post, Short 988640SRV 7-5 9
Assembly, Outer Extension Mount, Left 1007096SRV 7-23 13
Assembly, Push Bar 980027 7-4 1
Assembly, Screed Arm Mount, Left 1007024SRV 7-1 1
Assembly, Screed Arm Mount, Right 1007025SRV 7-1 -
Assembly, Screed Arm, Left 1007030SRV 7-31 2
Assembly, Screed Arm, Right 1007031SRV 7-32 2
Assembly, Screed Control 1008240SRV 7-31 1
Assembly, Screed Control Box, Right 1008241SRV 7-32 1
Assembly, Screed Extension (Left), 12" 1013573 7-37 27
Assembly, Screed Extension (Right), 12" 1013563 7-37 26
Assembly, Screed Extension, Left 1006378SRV 7-23 6
Assembly, Screed Extension, Right 1006379SRV 7-24 6
Assembly, Slide w/Shafts 1006416 7-22 1
Assembly, Slide without Shafts 1006445 7-22 2
Assembly, Spacer, Auger Shaft 1007306 7-18 27
Assembly, Top Back Plug 980417 7-13 8
Assembly, Truck Hitch 1008937SRV 7-41 -
Assembly, Turnbuckle w/Ratchet 983157 7-19 2
Assembly, Upper Screed Cover, Left 1008757 7-19 19
Assembly, Upper Screed Cover, Right 1008758 7-19 18
Assembly, Vandalism Cover 1007339 7-16 2
Assembly, Vertical Lift Adjuster 1006390 7-23 16
Assembly, Vertical Lift Adjuster 1006390 7-24 16
Assembly, Vibrator, Left 1008449SRV 7-21 1
Assembly, Vibrator, Right 1008448SRV 7-21 7
Auger Flight, Left, 12” 981700L 7-18 28
7
Alphabetical Parts Index
LeeBoy 8616B Conveyor Paver 7-91
