Description Part Number Figure Number Item Number
Auger Flight, Right, 12” 981700R 7-18 -
Auger Mount, Left 860051HDLSRV 7-18 -
Auger Mount, Right 860051HDRSRV 7-18 -
Axle, Guide Wheel 930045SRV 7-41 5
Ball Joint, 0.750, Male 1000947 7-23 18
Ball Joint, 0.750, Male 1000947 7-24 18
Bar, 0.25 x 1.5 x 36 985120 7-23 4
Bar, 0.25 x 1.5 x 36 985120 7-24 4
Bar, Adjustable Slide 851242SRV 7-38 13
Bar, Air Breather Mount 1010584 7-14 7
Bar, Cutoff Hinge 1007064 7-18 43
Bar, Element, Backup 1011155 7-27 3
Bar, Element, Backup 1011155 7-28 3
Bar, Element, Backup 1011155 7-29 3
Bar, Element, Backup 1011155 7-30 3
Bar, Element, Hold-Down 985121 7-19 9
Bar, Front Rubber Mount 980278 7-12 17
Bar, Idler, Side-Tapped 1006699 7-2 3
Bar, Push Bar Pin 856954 7-4 15
Bar, Roller Spacer, 1/4” 1007656 7-1 -
Bar, Round, Side-Wing Hinge 1007336 7-12 12
Bar, Screed Arm Stop 980439 7-31 3
Bar, Screed Arm Stop 980439 7-32 3
Bar, Shroud Hold-Down, Side 1011536 7-13 34
Bar, Tilt Screw Hold Down 980458 7-25 4
Bar, Tilt Screw Hold Down 980458 7-26 4
Bar, Vertical Lift 1006395 7-23 8
Bar, Vertical Lift 1006395 7-24 8
Bar, Vertical Lift Gauge 1006397 7-23 12
Bar, Vertical Lift Gauge 1006397 7-24 12
Bar, V-Groove Bottom Rail 1006426 7-19 16
Bar, V-Groove Top Rail 1006425 7-19 15
Battery, 12V, 1260 CCA - 7-8 9
Bearing, Auger 1007267 7-18 24
Bearing, Insert, 1.50 850130 7-3 21
Bearing, Insert, 1.50 850130 7-3 33
Bearing, Insert, 1.50 850130 7-4 5
Bearing, Radial Ball, 1.50 930050 7-41 4
Bearing, Roller 1 1/4” 810110 7-33 9
Belt, Fan 1009253-20 7-7 17
Alphabetical Parts Index
LeeBoy 8616B Conveyor Paver7-92
