Description Part Number Figure Number Item Number
Blaw Knox Kit (Replaces Item# 17) 20986170 7-33 19*
Blaw Knox Kit (Replaces Item# 4) 20986741 7-33 18*
Block, Terminal 985138-04 7-34 6
Block, Terminal 985138-04 7-35 6
Block, Terminal 985138-04 7-36 8
Bogie Shaft w/Flange 1006686 7-1 9
Bolt, 1/2-13, Conveyor Bearing 1009055 7-3 36
Bracket, ECU Mount 1009253-01 7-7 10
Bracket, Oil Cooler Mount 1010158 7-13 11
Bracket, Relay Mount 36086 7-17 11
Bracket, Sonic Sensor 1006451 7-25 9
Bracket, Sonic Sensor 1006451 7-27 6
Bracket, Sonic Sensor 1006451 7-28 6
Bracket, Sonic Sensor 1006451 7-29 6
Bracket, Sonic Sensor 1006451 7-30 6
Bracket, Sonic Tracker 851578 7-40 17
Bracket, Track Tension 980059 7-2 16
Bracket, Z Arm 9090-1125SRV 7-40 11
Bracket., Left Depth Screw Bottom Mount 1006571 7-25 3
Bracket., Right Depth Screw Bottom Mount 1006452 7-26 3
Bracket., Sonic Sensor 1006451 7-26 9
Breather Cap, 1/4” 620050 7-9 24
Breather, Cap, 1/4” 620050 7-8 14
Bushing 810070 7-4 16
Bushing, 1.00ID x 1.25OD x 1.00 220360 7-2 -
Bushing, 2.00 ID x 2.50 OD x 2.50 810070 7-41 12
Bushing, 2.00 ID x 2.50 OD x 2.50 Idler 810070 7-18 32
Bushing, Bogie Roller 1006691 7-1 8
Bushing, Composite, Power Crown 1000960 7-37 -
Bushing, Fiber, 2.25 OD x 2.00 ID 1006417 7-22 3
Cable, .063 851246 7-38 5
Cable, .063 851246 7-39 6
Cable, Auger Sensor 980550 7-25 11
Cable, Auger Sensor 980550 7-26 11
Cap, Adjuster Handle 1006434 7-33 6
Cap, Fuel 982033 7-8 6
Cap, Radiator, 13.5 psi, 2.25” Neck 1002184-04 7-7 29
Capacitor, Generator, 20 uF 1002146 7-11 -
Capacitor, Generator, 25 uF 1002147 7-11 -
Capacitor, Generator, 30 uF 1002148 7-11 -
7
Alphabetical Parts Index
LeeBoy 8616B Conveyor Paver 7-93
