LeeBoy 8616B - Engine Specifications

Table 2-1. Dimension Specications
ITEM SPECIFICATION
Overall Length 15 ft 4 in (4,674 mm)
Overall Height 8 ft (2,438 mm)
Transport Height (less exhaust) 8 ft (2,438 mm)
Overall Transport Width (with hopper up) 8 ft 6 in (2,591 mm)
Overall Width (with hopper down) 10 ft (3,048 mm)
Weight (with screed) 20,600 lb (9,344 kg)
Main Screed Width 96 in (2,438.40 mm)
Main Screed Wear Plate Depth 16.75 in (425.45 mm)
Main Screed Wear Plate Material .5 in (12.7 mm) AR400 Steel
Main Screed Wear Plate Thickness .50 in (12.7mm)
Bullnose Radius 2 in (50.80 mm)
Extensions Wear Plate Material .375 in (9.52 mm) AR400 Steel
Extensions Wear Plate Thickness .375 in (9.52 mm)
Extensions Bullnose Radius 1.50 in (38.10 mm)
Wheelbase Track Ground Contact Length 7 ft 7 in (2302 mm)
Ground Clearance 6.62 in (168 mm)
Gauge Width Outside Wheels and Tracks 7 ft 7 in (2302 mm)
Table 2-2. Kubota Tier 4 Engine Specications
ITEM SPECIFICATION
Manufacturer Kubota, Tier 4i, Turbo-Charged
Model V3800-CR-TE4
Fuel Type Diesel
Cylinders 4
Rated Speed 2,600 rpm
High Idle 2,400 rpm
Max Gross Power 99.9 hp (73.8 Kw)
Max Gross Torque 249.44 ft lb (338 Nm)
Displacement 230 in 3 (3.769 L)
2
LeeBoy 8616B Conveyor Paver
2-5
Information and Specications
