LeeBoy 8616B - Electrical Specifications

Table 2-3. Electrical Specications
ITEM SPECIFICATION
Battery One (1), Maintenance-Free
Battery Ampere per Hour Rating 1,125 CCA
Battery Voltage 12 V
Alternator Type and Voltage 12 V, Negative Ground
Alternator Output Amperage 100 Amps
Alternator Fan Belt Tension
Automatic belt tension mechanism keeps serpentine
belt under tension at all times.
Starter Voltage and Type 12 V, Negative Ground
Starter Rating 3 kW
Table 2-4. Performance Specications
ITEM SPECIFICATION
Transport Speed 3.64 mph (5.56 kph)
Paving Speed 1.32 mph (2.12 kph)
Maximum Paving Depth 6 in (152 mm)
Maximum Paving Width (Hydraulic) 15 ft (4.57 m)
Basic Paving Width 8 ft (2.44 m)
Turning Radius 5.5 ft (1,676.4 mm) (Capable of Counter-Rotation)
Table 2-5. Machine System Capacity Specications
ITEM SPECIFICATION
Hydraulic 41 gal (155 L)
Fuel 32 gal (121 L)
Engine Oil with Filter 14 qt (13.24 L)
Coolant 14.4 qt (13.6 L)
Washdown 7 gal (26.50 L)
Hopper 9 T
Table 2-6. Hydraulic Filters
ITEM SPECIFICATION
Primary Filter Type Charge Filter
Primary Filter Size 7 Microns
Primary Filter Location Engine Compartment (right side mounted to fuel tank)
Secondary Filter/Strainer Type
Suction Strainers (Stauff TMF-2534-0-5); Return Filter
(Schroeder KBZ10)
Secondary Filter/Strainer Size
Suction Strainers (125 Micron) Return Filter (10 Micron)
Secondary Filter/Strainer Location
Suction Strainers (inside hydraulic tank); Return Filter
(top of hydraulic tank)
