Table 2-14. Generator Specications
ITEM SPECIFICATION
Model HMCC-1201DHW-18
Power 12 KW (12,000 Watt)
Voltage 120/240 V
Frequency 58 - 60 HZ
Table 2-15. General Purpose Pump Specications
ITEM SPECIFICATION
Model Series 45
Displacement (Maximum) 4.58 in3 (75 cc)
Relief Pressure 2,900 psi (200 bar)
Input Speed 2,600 rpm
Flow at Input Speed 47.4 gpm (179.40 lpm)
Input Flange and Spline 2-bolt B 13T 8/16
Controls Load Sensing
Table 2-16. Track Specications
ITEM SPECIFICATION
Length 220.47 in (5600 mm)
Width 14 in (355.6 mm)
Type Poly (Smooth Poly - Optional)
Brand Berco - Poly (Superior - Smooth)
Quantity of Pads 40 pads per side (80 total)
Planetary Drive Yes
Number of Speeds 2-Speed
Brakes Spring-Applied Hydraulic Released (SAHR)
