Table 2-9. Propulsion and Pump Specications
ITEM SPECIFICATION
Displacement (Maximum) 2.75 in 3 (45 cc)
Relief Pressure 3,625 psi (250 bar)
Input Speed 2,600 rpm
Flow at Input Speed 30 gpm (113.50 lpm)
Input Flange and Spline 2-bolt "B" 14T 12/24
Auxiliary Pad 13T B
Controls EDC
Table 2-10. Motor Specications
ITEM SPECIFICATION
Displacement (Maximum) 3.66 in (60 cc)
Input Flow max 30 gpm (113.50 lpm)
Maximum Output Torque 167.30 ft-lbs (226.80 Nm)
Output Speed 1,873 rpm
Output Flange and Spline 14T Cartridge
Weight 59 lbs (27 kg)
Table 2-11. Auger and Conveyor Motor Specications
ITEM SPECIFICATION
Displacement (Maximum) 15.26 in (250 cc)
Input Flow (Maximum) 19.8 - 23.8 gpm (75 - 90 lpm)
Output Speed 300 - 360 rpm
Output Flange and Spline 4-Bolt Magneto Flange w/Cyl 1"- Splined 1"
Table 2-12. Auger and Conveyor Drive Specications
ITEM SPECIFICATION
Max Auger Speed 116 rpm
Max Conveyor Speed 51.16 fpm (15.59 mpm)
Table 2-13. Planetary Drive Specications
ITEM SPECIFICATION
Model PGRF 1703
Ratio–Gear 82.188:1
Parking Brake Fail-safe
Parking Brake Release Pressure 200 psi (13.8 bar)
Gearbox Oil Designation (i.e 80W-90) 80W-90
Oil Capacity 3 qt (2.84 L)
