Legrand PDU User Guide 307
Enabling or Disabling the LAN Interface
This command enables or disables the LAN interface.
config:# network ethernet <ETH> enabled <option>
Variables:
 <ETH> is one of the options -- eth1 or eth2.
Option Description
eth1 ETH1 port
eth2 ETH2 port
 <option> is one of the options: true or false.
Option Description
true The specified network interface is enabled.
false The specified network interface is disabled.
Changing the LAN Interface Speed
This command determines the LAN interface speed.
config:# network ethernet <ETH> speed <option>
Variables:
 <ETH> is one of the options -- eth1 or eth2.
Option Description
eth1 ETH1 port
eth2 ETH2 port
 <option> is one of the options: auto, 10Mbps or 100Mbps.
Option Description
auto System determines the optimum LAN speed
through auto-negotiation.
10Mbps The LAN speed is always 10 Mbps.
100Mbps The LAN speed is always 100 Mbps.
