Legrand PDU User Guide 369
config:# sensor inlet <n> <sensor type> upperWarning <option>
 Set the Lower Critical threshold for an inlet sensor:
config:# sensor inlet <n> <sensor type> lowerCritical <option>
 Set the Lower Warning threshold for an inlet sensor:
config:# sensor inlet <n> <sensor type> lowerWarning <option>
 Set the deassertion hysteresis for an inlet sensor:
config:# sensor inlet <n> <sensor type> hysteresis <hy_value>
 Set the assertion timeout for an inlet sensor:
config:# sensor inlet <n> <sensor type> assertionTimeout <as_value>
Variables:
 <n> is the number of the inlet that you want to configure. For a single-inlet PDU, <n> is always 1.
 <sensor type> is one of the following sensor types:
Sensor type Description
current Current sensor
voltage Voltage sensor
activePower Active power sensor
apparentPower Apparent power sensor
powerFactor Power factor sensor
activeEnergy Active energy sensor
unbalancedCurrent Unbalanced load sensor
lineFrequency Line frequency sensor
phaseAngle Inlet phase angle sensor
Note: If the requested sensor type is not supported, the "Sensor is not available" message is displayed.
 <option> is one of the options: enable, disable or a numeric value.
Option Description
enable Enables the specified threshold for a specific inlet
sensor.
disable Disables the specified threshold for a specific inlet
sensor.
