370 Legrand PDU User Guide
Option Description
A numeric
value
Sets a value for the specified threshold of a
specific inlet sensor and enables this threshold at
the same time.
 <hy_value> is a numeric value that is assigned to the hysteresis for the specified inlet sensor. See "To
De-assert" and Deassertion Hysteresis (on page 477).
 <as_value> i
s a numeric value that is assigned to the assertion timeout for the specified inlet sensor.
See "To Assert" and Assertion Timeout (on page 475).
 Additional sensors
supported by Legrand PDUs:
The CLI command(s) listed above can be also applied to the following sensors. Note that the measurement
unit of current values in CLI is A, not mA.
Sensor type Description
peakCurrent Peak current sensor
reactivePower Reactive power sensor
displacementPowerFa
ctor
Displacement power factor sensor
phaseAngle Inlet phase angle sensor
Commands for Inlet Pole Sensors
A sensor configuration command for inlet poles begins with sensor inletpole. This type of command is
available on a three-phase PDU only.
You can configure various inlet pole sensor threshold settings at a time by combining multiple commands.
See Multi-Command Syntax (on page 381).
 Set the
Upper
Critical Threshold for an Inlet Pole:
config:# sensor inletpole <n> <p> <sensor type> upperCritical <option>
 Set the Upper Warning Threshold for an Inlet Pole:
config:# sensor inletpole <n> <p> <sensor type> upperWarning <option>
 Set the Lower Critical Threshold for an Inlet Pole:
config:# sensor inletpole <n> <p> <sensor type> lowerCritical <option>
 Set the Lower Warning Threshold for an Inlet Pole:
config:# sensor inletpole <n> <p> <sensor type> lowerWarning <option>
 Set the Inlet Pole's Deassertion Hysteresis:
config:# sensor inletpole <n> <p> <sensor type> hysteresis <hy_value>
 Set the Inlet Pole's Assertion Timeout:
