Maximum Ambient Operating Temperature
Make sure the environment does NOT exceed the maximum ambient operating temperature (TMA) when
operating your Legrand PDU. If necessary, contact Legrand Technical Support for this information of your
model.
Specification
Measure
Max Ambient Temperature 45 degrees Celsius
Serial RS-232 "RJ-45" Port Pinouts
RJ-45 Pin/signal definition
Pin No. Signal Direction Description
1 N/A ― No signal
2 N/A ― No signal
3 TxD Output Transmit data
4 GND ― Signal ground
5 N/A ― No signal
6 RxD Input Receive data (data in)
7 N/A ― No signal
8 N/A ― No signal
Sensor RJ-45 Port Pinouts
RJ-45 Pin/signal definition
Pin No. Signal Direction Description
1 +12V ― Power (fuse protected)
2 +12V ― Power (fuse protected)
