Using your Edger...Usual procedure
3-37
LTO
3.2.3.2.6 OVERSIZE OF A SHAPE
Lens compensation involves applying an oversize or not (defined in the machine settings).
You may change the proportional compensation value, using the entry button (2).
If no compensation is necessary, simply press the button (1).
Screen 3-12 : Lens compensation screen
Used to scroll over
several predefined
oversizes.
(OK, +, ++)
Manual entry of the over-
size to be applied. (besi-
des predefined values)
