4-56
Application Manual CDA3000
4 Application data sets
The parameter presets for application data sets M-S_x are located as
parameter comparison references in section 4.6.5 “Comparison of para-
meters, Master/-Slave operation”.
Input signals
(1) Analog reference value of ISA00
(2) DC braking torque
Figure 4.40 Example of a driving profile for two directions of rotation
(ASTER=M-S_2)
The characteristic of the output signals is shown in section 4.6.1 “M-S_1”
in Figure 4.38.
t [ms]
0
f [Hz]
v [m/s]
0
1
0
1
STR
STL
(2)
590-ACCR1
590-ACCR1
590-ACCR1
(1)
(1)
(1)
594-STPR1
592-DECR1
