262335 21 Revision A
1009172
B
A
Figure 3.19: Shipping Stands
6. Remove four bolts (A) and remove angle (B). Discard angle
and hardware.
1031232
A
Figure 3.20: Center Deflector – Non-GSS Only
7. Non-GSS headers only: Remove the straps that attach
center deflector (A) to the conditioner.
ASSEMBLING THE MACHINE
