MacDon D65 - Page 30

214327 10 Revision B
1024538
A
B
C
E
F
G
A
C
D
G
B
D
A
B
G
D
E
F
H
H
Figure 1.18: Endsheets, Reel Arms, Backsheet
A - MD #131393 (2 Places) B - MD #174632 (2 Places) C - MD #184422 (Single Knife – Left
Side Only, Double Knife – Both
Sides)
D - MD #184422 (Single Knife – Left Side
Only
1
, Double Knife – Both Sides
E - MD #131392 (Double Reel – 2 Places) F - MD #131391 (2 Places) G - MD #174436 H - MD #131393 (Single Reel – 2 Places)
SAFETY
1. There is no decal on 4.6 m (15 ft.) headers.
