214327 11 Revision B
1024707
A
B
C
C
B
A
B
C
D
D
Figure 1.19: Backtube – 4.5 m (15 ft.) Draper Rigid Header
A - MD #184422 B - MD #184372 C - MD #131391 D - MD #166466
SAFETY
