Table 2.1 Header Specifications (continued)
Knife overlap at center (double-knife headers) 3 mm (0.12 in.)
S
Guards and Hold-Downs
Guard: pointed / forged / double heat treated (DHT)
Hold-down: sheet metal / adjustment bolt
O
F
Guard: pointed / forged / case hardened (CH)
Hold-down: sheet metal / adjustment bolt
O
F
Guard: stub / forged bottom / forged top / adjustment plate
O
F
Guard: stub / forged bottom / sheet metal top / adjustment bolt
O
F
Guard: four point / no-choke design (two long points with tangs / two short points without tangs)
O
F
Guard Angle (Cutterbar on Ground)
Center-link retracted
4.6–7.6 m
(15–25 ft.)
7.5 Degrees
S
Center-link retracted
9.1–12.2 m
(30–40 ft.)
2.5 Degrees
S
Center-link extended
4.6–7.6 m
(15–25 ft.)
17.0 Degrees
S
Center-link extended
9.1–12.2 m
(30–40 ft.)
12.0 Degrees
S
Conveyor (Draper) and Decks
Draper width
1057 mm (41.6 in.)
S
Draper drive
Hydraulic
S
Draper speed
0–225 m/min. (0 –742 fpm)
S
Delivery opening width (center delivery) /
variable by shifting decks
4.6 m (15 ft.)
1540–1770 mm
(60.6–69.7 in.)
S
Delivery opening width (center delivery) /
variable by shifting decks
6.1–12.2 m
(20–40 ft.)
1720–1950 mm
(67.1– 76.7 in.)
S
