214327 27 Revision B
Table 2.1 Header Specifications (continued)
PR15 Pick-Up Reel
Delivery opening height (under frame tube at
203 mm [8 in.] cutting height)
Center-link fully
retracted
955 mm (37.6 in.)
S
Delivery opening height (under frame tube at
203 mm [8 in.] cutting height)
Center-link fully
extended
1105 mm (43.5 in.)
S
Quantity of tine tubes
5, 6, or 9
—
Center tube diameter: all reel sizes except 10.7 m (35 ft.) single reel
203 mm (8 in.)
—
10.7 m (35 ft.) single header reel only 254 mm (10 in.)
—
Finger tip radius
Factory-set
800 mm (31.5 in.)
—
Finger tip radius Adjustment range
766–800 mm
(30.2– 31.5 in.)
—
Effective reel diameter (via cam profile) 1650 mm (65 in.)
—
Finger length
290 mm (11 in.)
—
Finger spacing (staggered on alternate bats) 150 mm (6 in.)
—
Reel drive Hydraulic
S
Reel speed (auto-adjust from cab using ground speed index)
0–85 rpm S
Frame and Structure
Header width (field mode)
Cut width + 384 mm
(15.12 in.)
S
Header width (transport mode—
reel fore-aft fully retracted)
Header only
(B)
3
,
4
2636 mm (104 in.) —
Header width (transport mode—
reel fore-aft fully retracted)
Header only
(A)
3
,
5
2452 mm (97 in.) —
Header width (transport mode—
reel fore-aft fully retracted)
With HC10 Hay
Conditioner installed
(B)
3
,
4
2834 mm (112 in.)
—
Header width (transport mode—
reel fore-aft fully retracted)
With HC10 Hay
Conditioner installed
(A)
3
,
5
2650 mm (104 in.)
—
PRODUCT OVERVIEW
3. Refer to Figure 2.1, page 28
4. Long dividers installed
5. Long dividers removed
