Maintenance work on the carrier
7.13 Hydraulic system
03.11.2017
Maintenance manual 3 302 574 en 7 - 99
GMK3060
Prerequisites – The engine must not be running and must be secured against unauthor-
ised use;
à p. 2 - 3.
– The hydraulic system is depressurised.
Changing oil
filters 1 and 2
• Undo the screws on the right and left of the
cover (1) and remove it.
• Place a receptacle under the oil filters.
• Unscrew the filter (2).
• Place the filters in a receptacle.
• Screw on new filters - slightly grease the
gasket.
• Fasten the cover (1).
s
O
Risk of damage to the environment from filter residues!
Store used hydraulic oil filter inserts in suitable receptacles and have them
disposed of properly by qualified personnel.
