MLA System USER GUIDE
MLA System User Guide V2.1 21
of a few millimetres, where cabinets are projecting over distances of up to 100 metres a few millimetres will have enough of an
impact on the cabinet angle to make a difference of several metres to the coverage area of a particular cabinet.
The bar travels in the parked position with the connecting pin in the central hole which ensures that the bar and pin are flush
with the cabinet sides thus avoiding damage in transit.
The rear bracket also has a parked position with the pin in a central hole which retains the linking bar when in transit
One issue with previous Martin Audio rigging system was the difficulty experienced flicking the rear linking bar out of its parked
position. This problem has been solved with the addition or a protruding tongue at the base of the bar where it pivots. This can
easily be used to rotate the bar out of its slot once the securing pin has been removed.
