AlgoMed Technical Reference Manual
Proprietary 50 of 110
4. Type the program name.
For faster identification, it is advisable to type a meaningful name.
5. Click OK.
The Program Details screen is displayed (see below) where you can edit the program
parameters (see following section).
7.3 Editing Program Parameters
The program details screen enables the operator to edit the program details and parameters.
Below is a description of the available editing operations which are shown in the left side bar:
Displays a list of the program revision history by version date and username.
Displays the Test Instructions Editor for editing unique test instructions. Refer
to section X 2X, page X55.
Returns to the previous menu.
Copies the selected record (sequence).
Pastes the copied record to the right of the selected record.
Adds a new record to the end of the current program.
Adds a new record to the left of the selected record.
Previews the program graph.
Checks program validity, and marks missing or incorrect parameters.
Saves the information displayed.
7.3.1 Program Details
The following screen enables the formation of program protocols.
Following are sampled menus:
7.3.1.1 Limits
In this method, the operator generates a number of stimuli of continuously changing intensity.
With each stimulus, when the subject perceives a predefined sensation, he/she notify the
operator who stops the stimulus. Optional Patient Response Unit is available to allow marking
of exact pressure.
