10.3.1 Test Configuration
The Test Configuration option enables you to set default test display parameters.
Figure 56: Test Configuration Settings
The available settings are described in the table below:
Table 23: Test Settings Options
Parameter
Description
Sound Feedback
Tolerance
Define margins in percentage to sound feedback to be
display and heard
Min. Detection
Pressure
Minimum Pressure to be detect by software
Show CoVAS
View/Hide CoVAS display. CoVAS display is currently not
available for the AlgoMed system.
Show Normative
Data
Currently not available for AlgoMed
Default Time Scale
Default time display on screen
Show Current Value
Display pressure value in real time
Pressure scale
Default pressure range display (min, max) for Algometer
