AlgoMed Technical Reference Manual
Proprietary 55 of 110
between sequences if needed.
2. Select the request mark type:
c. TTL – a mark will be displayed on screen and indication will be added to test results
and visible in excel export.
d. Snd – a sound will be played. To configure the sound refer to section 10.3.5.
3. Click anywhere on the screen, or on the X mark at the corner of the window, to close the
Standard Events dialog.
7.4 Unique Test Instructions
In some cases, the general program instructions do not fully apply to specific programs, and
unique instructions are required.
To enter unique instructions, perform to the following procedure. All other (standard) tests will
be assigned the standard instructions, as entered in section 10.3.2, page 90.
1. From the program list at the left, select the required program, and double-click, or click the
Edit program details button .
The Programs menu is displayed.
2. Click the Accesses test instructions button .
The following screen is displayed:
Figure 34: Test Instructions Editor
3. To edit the textual instructions,
3.1. Deselect the relevant Use default instruction checkbox.
The Edit button becomes enabled.
3.2. Click the Edit button.
The text editor is displayed, displaying the standard instructions.
3.3. Edit the instructions as required, as described in section 10.3.2.1, page 90.
4. To replace the audio instructions,
4.1. Deselect the relevant Use default instruction checkbox.
The Play button becomes an enabled Browse button.
4.2. Click the Browse button.
The Audio instruction screen is displayed.
4.3. Replace the instructions file, as described in section 10.3.2.2, page 91X
7.5 Removing A Program
To remove a program from the program list:
1. Click the Remove icon ( ).
2. Click Yes to the prompt.
The selected program is deleted.
