Appendix D - Vials and Vial Shields
Table 8: Vial Shield and Vial Specifications - Violet
Vial Shield Vial(s)
Medrad Part
Number
Collar
Color
Weight Volume
Range
ISO 8362-
1:2003
ISO 8362-
4:2003 Size
Specification
Body Diameter Glass Height Cap
Diameter
3037589 Violet
8.6 kg
(18 lbs)
10 ml -----
21.25 ± 0.2 mm
(0.837 ± 0.007")
51 ± 0.5 mm
(2.008 ± 0.020")
20 mm
(0.787")
21.75 ± 0.25 mm
(0.856 ± 0.009")
52 ± 0.5 mm
(2.047 ± 0.020")
20.0 mm (0.787”)
20,0 mm (0,787”)
52.0 mm 0.5 mm
(2.047” 0.020”)
±
±
±
±
52,0 mm 0,5 mm
(2,047” 0,020”)
21.75 mm 0.25 mm (0.856 0.009”)±±
±±21,75 mm 0,25 mm (0,856 0,009”)
21.25 mm 0.2 mm (0.837 0.007”)±±
±±21,25 mm 0,2 mm (0,837 0,007”)
20.0 mm (0.787”)
20,0 mm (0,787”)
51.0 mm 0.5 mm
(2.008” 0.020”)
±
±
±
±
51,0 mm 0,5 mm
(2,008” 0,020”)
