Medrad™ Intego™
PET Infusion System
4
Label showing the correct and incorrect direction to attach the
Needle Cartridge into the Needle Cartridge Holder.
Label showing the correct and incorrect insertion of the tubing into
the Air Detector.
Label showing the correct and incorrect orientation of the T-
Connector and the tubing in each of the Pinch Valves.
Label showing the correct and incorrect method of inserting the
tubing into a Pinch Valve.
The following Product Symbols apply only to INT SYS 200 systems.
Indicates Drive Speed Switch is in fast speed range position.
Indicates Drive Speed Switch is in slow speed range position.
The following Product Symbol applies only to INT SYS 100 systems.
Brake release triggers.
Warnings
Attention symbols used to identify warnings and cautions in
product labeling.
Pinch hazard. This symbol indicates there is the potential for pinch
injury.
Crush hazard. This symbol indicates there is the potential for
crush injury.
