Functional Principle, Technical Data
optoNCDT 1700
Type ILD 1700- 2 10 20 40 50 100 200 250VT 300 500 750
Operating
temperature
0 ... +50 °C 0 ... +55 °C 0 ... +50 °C
Storage temperature -20 ... +70 °C
Protection class IP 65 (with plugged connection)
Power supply U
B
24 V (11 ... 30 V) DC; max. 150 mA
Measurement value
output
selectable 4 -20 mA; 0 -10 V; RS422
Voltage output R
i
= 100 Ohm, I
max
= 5 mA, short-circuit proof
Load current output R
Load
< (U
B
-6 V) / 20 mA, R
Load
250 Ohm for U
B
= 11 VDC
Switching outputs programmable Error or/and limit values, short-circuit proof
Switching inputs Laser ON/OFF; Zero
Synchronization programmable Simultaneous or alternating
Sensor cable
Standard
Extension
0.25 m (with cable jack)
3 / 10 m
Electromagnetic compatibility (EMC)
EN 61326-1: 2006-10
DIN EN 55011: 2007-11 (Group 1, class B)
EN 61 000-6-2: 2006-03
Vibration (acc. to IEC 60068-2-6)
2
2 g / 20 ... 500 Hz
Shock (acc. to IEC 60068-2-29)
2
15 g / 6 ms
Housing size S M
Weight (with 25 cm cable) 550 g 600 g 550 g 550 g 600 g
The specified data apply to a white, diffuse reflecting surface (Reference: Ceramic).
SMR = Start of measurement range; MMR = Midrange; EMR = End of measuring range
FSO = Full Scale Output
1) At a measurement frequency of 2.5 kHz, without averaging
2) ILD1700-250VT: 20 g, vibration and shock resistant sensor model for use on vehicles
