Functional Principle, Technical Data
optoNCDT 1700
optoNCDT1700 - for direct reflective surfaces
Type ILD 1700- 2DR 10DR 20DR
Measuring range mm 2 10 20
Start of measuring range mm
Dimensional drawing, see Fig. 16, et seq.
Midrange (MMR) mm
End of measuring range mm
Linearity, j/2
FSO ±0.1 % ±0.1 % ±0.2 %
Linearity, j/2 ±0.3 °
FSO ±0.2 % ±0.25 % ±2 %
2
Resolution
1
µm 0.1 0.5 3
Tilt angle (j/2)
20 ° 17.6 ° 11.5 °
Housing size S
Not specified data correspond to those of the standard sensors.
MMR = Midrange
FSO = Full Scale Output
1) At a measurement frequency of 2.5 kHz, without averaging
2) Measuring range 18 (.71)
optoNCDT 1700LL - for metallic shiny and rough surfaces
Type ILD 1700- 2LL 10LL 20LL 50LL
Measuring range mm 2 10 20 50
Spot diameter
SMR 85 x 240 µm 120 x 405 µm 185 x 485 µm 350 x 320 µm
MMR 24 x 280 µm 35 x 585 µm 55 x 700 µm 70 x 960 µm
EMR 64 x 400 µm 125 x 835 µm 195 x 1200 µm 300 x 1940 µm
Housing size S
For measurements against high glossary surfaces (targets), resolution depends on the material.
Not specified data correspond to those of the standard sensors.
SMR = Start of measurement range; MMR = Midrange; EMR = End of measuring range
Legend:
mm (inches)
