Page 17
Functional Principle, Technical Data
optoNCDT 1700
optoNCDT 1710 - for long distance to the target
Type ILD 1710-50 ILD 1710-1000
Measuring range mm 50 1000
Start of measuring range mm 550 1000
Midrange (MMR) mm 575 1500
End of measuring range mm 600 2000
Linearity mm ±0.05 ±1
Resolution
1
µm 5 100
Spot diameter
SMR 0.4 ... 0.5 mm 2.5...5 mm
MMR 0.4 ... 0.5 mm 2.5...5 mm
EMR 0.4 ... 0.5 mm 2.5...5 mm
Sensor cable 0.25 m integrated
Weight ca. 0.8 kg
Protection class IP 65
Temperature stability % FSO/ °C 0.01
Operating temperature °C 0 ... 50
Housing size L
Not specified data correspond to those of the standard sensors.
SMR = Start of measurement range; MMR = Midrange; EMR = End of measuring range
FSO = Full Scale Output
1) At a measurement frequency of 2.5 kHz, without averaging
