Page 25
Installation
optoNCDT 1700
35 (1.38)
17.5
(.69)
18.5
(.73)
75 (2.95)
40
Mounting
holes
3 x ø 4.5 mm
(.18 dia.)
70 (2.76)
80 (3.15)
15
(.59)
Laser spot
130
(5.12)
140 (5.51)
150 (5.91)
5
(.20)
20xx
Fig. 11 Dimensional drawing
optoNCDT 1700-40/300/500/750
optoNCDT 1700-500/750BL
dimensions in mm, not to scale
Housing size M
