MICRO-EPSILON ILD1700-2 - Page 24

Page 24
Installation
optoNCDT 1700
Fig. 10 Free space for optics
optoNCDT 1700-20/200BL
dimensions in mm, not to scale
30 (1.2)
13.2
(.52)
15
(.59)
67 (2.6)4
(.16)
75 (3.0)
80 (3.15)
89 (3.5)
97 (3.82)
37.5 (1.48)
Mounting
holes
3 x ø 4.5
(.18 dia.)
24.2
(.95)
36.1 (1.4)
13.4
(.53)
A
B
ø 8
(.31 dia.)
15
(.59)
13.4
(.53)
SMRMR



ø 4
(.16 dia.)
Fig. 9 Dimensional drawing
optoNCDT 1700-20/200BL
dimensions in mm, not to scale
MR SMR
a e
A B
20 40 28.8 ° 26.7 ° 30.1 22.0
200 100 13.5 ° 6.3 ° 33,1 24.1
SMR = Start of measuring range
MR = Measuring range
Housing size S
