Installation
optoNCDT 1700
5
(0.20)
61 (2.40)
73 (2.87)
5
(0.20)
95 (3.74)
190 (7.48)
(ø6)
83 (3.27)
71 (2.80)
200 (7.87)
85 (3.34)
24
(0.95)
48
(1.89)
47 (1.85)
Control
panel
14
(0.55)
147 (5.79)
ø 9
max. opt.
effective
50
±1
(1.97 ±0.04)
ø16 (.63 dia.)
ø 20 (0.79 dia.)
Laser spot
ø 32
(1.26 dia.)
17.5 ±1
(0.69 ±0.04)
Fig. 13 Dimensional drawing
optoNCDT ILD 1710-50/1000
optoNCDT ILD 1710-50/1000BL
dimensions in mm, not to scale
Housing size L
