MICRO-EPSILON ILD1700-2 - Page 28

Page 28
Installation
optoNCDT 1700
SMR
MR
144 (5.67)
ø 33
(1.29
dia.)



ø 9
(.35 dia.)
(4.65°)
(7.45°)
Connection
cable
0.25 m
Minimum visual range
of the sensor to be kept free.
24 (0.95)
ø 9
(.25
dia.)
Label
Fig. 14 Free space for optics
optoNCDT ILD 1710-50/1000,
optoNCDT ILD 1710-50/1000BL,
dimensions in mm, not to scale
MR SMR
a e
50 550 13.35 ° 15.15 °
1000 1000 7.45 ° 4.65 °
