MICRO-EPSILON ILD1700-2 - Page 30

Page 30
Installation
optoNCDT 1700
15
(.59)
45.7 (1.80) 29
(1.14)
13.4
(.53)
28.3 (1.11)
32.3 (1.27)
91.1 (3.59)
96.2 (3.79)
49.2 (1.94)
35.5
(1.40)
90 °
MB 10
(.39)
5 (.20)
17.6 °
Direct reflecting target
Fig. 17 Dimensional drawings optoNCDT1700-10DR (not to scale)
MR = Measuring range
Legend:
mm (inches)
