Installation
optoNCDT 1700
Fig. 18 Dimensional Drawings range optoNCDT1700-20DR (not to scale)
MR = Measuring range
15
(.59)
90 °
MR 20 (.79)
10
(.39)
Direct reflecting target
49.6
(1.95)
30.9
(1.22)
44.3
(1.74)
13.4
(.53)
63.5
(2.50)
58.6 (2.31)
62.6 (2.46)
113.2 (4.46)
128.2 (5.05)
11.5 °
Legend:
mm (inches)
