Page 69
Serial Interface RS422
optoNCDT 1700
Measurement range:
Integer in hex form in mm
Key lock:
0 = Keys enabled
1 = Keys locked
Digital data output:
0 = Data output switched off
1 = Data output switched on
Enable Flash:
0 = Flashwrite locked
1 = Flashwrite enabled
Format: 31 24 23 16 15 8 7 0 hex
„+“ „+“ „+“ 0x0d („CR“) 0x2B2B2B0D
„l“ „L“ „D“ „1“ 0x494C4431
0x20 0x4A 0x00 0x02 0x204A0002
Reply: 31 24 23 16 15 8 7 0 hex
„l“ „L“ „D“ „1“ 0x494C4431
0xA0 0x4A 0x00 0x17 0xA04A0017
Output type
0x00 0x00 0x00 0x0X 0x0000000X
Measurement speed
0x00 0x00 0x00 0x0X 0x0000000X
Averaging number
0x00 0x00 0x00 0x0X 0x0000000X
